· New rear driveshaft transmission with top and bottom right-angle gearboxes connected with each other by means of a cardan shaft.
· The augers’ guards are free from obstacles for a better grain flow.
· Less maintenance needed.
· Unloading performance: 380 t/h
· Power required: from 90 HP
· Rolls 9 and10-ft bags up to 500-ft long.
· Tube/auger diameter: 430 mm (17 in)
· Horizontal auger diameter: 250 mm (9 3/4 in)
· Maximum hydraulic power: 180 bar 60 LPM.
· Simple to adjust: It is very easy to swing into transport or working position.
· Modern design: allows an easier unloading operation and minimizes the risk of bag damage.
· Grain pusher: It ensures a better end of bag.
· Hydrostatic movement: The machine moves automatically as the bag is winded up by the roll. It has a speed adjustment system and a sturdy reduction gearbox.
· Extra-reinforced chassis.
· Independent hydraulic controls
· Adjustable knife: to cut the bag at the ideal angle.
· Axles and tires: Reinforced axle system to accommodate the extra weight when unloading in wet and soft ground conditions. High flotation tires (400 x 60 x 15.5”).
· Electrostatic polyurethane paint
